Autronica BS100 DYFI Fire Alarm Control Panel

Autronica BS100 DYFI Fire Alarm Control Panel – Safety Critical Equipment The Autronica BS100 DYFI is a high-end analog addressable fire alarm control panel with marine rating, designed for medium to large commercial ships, offshore platforms and heavy industrial buildings. The BS100 is recognised worldwide as important safety equipment and is based on Autronica’s exclusive DYFI® (Dynamic Filter Process) technology. The innovative software platform employs adaptive dynamic filtering to identify true combustion signatures from spurious, non-fire events (such as diesel fumes, steam or dust) and thereby virtually eliminates costly and disruptive false alarms in high-vibration maritime applications.   Model Details: Brand: Autronica Model/Series: BS-100 / BS100 DYFI Manufacturer Part Number (MPN): 116-BS-100 Product Category: Marine Fire Detection Systems Country of Origin: India Specifications Parameter Specification Details Operating Voltage 230 VAC Base (Internal Transformer System: Prim 110V/220V 50Hz, Sek 24 VDC nominal) Backup Battery Monitoring Automatic self-diagnosis (Fault alerts triggered if battery drops < 22.5V or rises > 28.5V) Standard Capacity 2 Detector Loops (Up to 99 unique addressable field devices per loop) Maximum Expandability Up to 16 Loops (Supporting up to 1,584 addressable devices total) Loop Cable Resistance Limit Strictly Maximum 30 Ohms Interface Options RS232C & 20 mA current loop for remote mimic panels, repeaters, or VDR/BMS output Display Panel 2 x 40 Character fluorescent dot-matrix alphanumeric screen Enclosure Rating & Certification IP23 / IP34 options; Tested and fully compliant with BS-5839 Part 4: 1988   Applications Commercial merchant vessels have engine rooms, cargo holds, control rooms, and accommodation decks. Offshore platforms and FPSOs require safety-critical open-deck zoning and hazardous zone monitoring. Industrial Plants: Power generation hubs, manufacturing complexes, and marine ports necessitate robust addressable network designs.
